• JDIKD1.5-BU Triple-Level Screw Terminal Block, Blue | 2.5 mm², 26A 250V, 6.2 mm Wide | Three-Tier Sensor/Actuator DIN-Rail Terminal | Pack of 50
JDIKD1.5-BU
JDIKD1.5-BU

JDIKD1.5-BU Triple-Level Screw Terminal Block, Blue | 2.5 mm², 26A 250V, 6.2 mm Wide | Three-Tier Sensor/Actuator DIN-Rail Terminal | Pack of 50

$103.86 USD
$2.08 pc

Shipping calculated at checkout.

Selling quickly! people have this item in their carts
In stock!
Order Unit: 50 pcs
Select The Options Above

The JDIKD1.5-BU is a blue triple-level screw terminal block, rated 26 A / 250 V for conductors from 0.2 to 4 mm². Three levels in one 6.2 mm housing allow complete three-wire sensor or actuator connections at a single rail position.

Technical Specifications

Model JDIKD1.5-BU
Order number 1010.055
Product type Triple-level terminal block
Colour Blue
Connection type Screw connection
Nominal cross section 2.5 mm²
Wire cross section 0.2–4 mm²
Rated current / voltage 26 A / 250 V
Dimensions (T × H × W) 6.2 × 56 × 73 mm
Connection standard IEC 60947-7-1
Flammability class UL 94 V0
Marker strip ZB6
Fixed bridge FBI 10-6
Insertion bridge EB 165-JDIK BU / EB 165-JDIK RD

Packaging

Units per box 50 pcs
Box dimensions (L × W × H) 17 × 15 × 5.5 cm
Box gross weight 1.14 kg
Units per carton 1,500 pcs
Carton dimensions (L × W × H) 51 × 35 × 33 cm
Carton gross weight 32.56 kg

The LEIPOLE JDIKD1.5-BU is a blue triple-level screw terminal block for 2.5 mm² conductors, rated 26 A / 250 V and 6.2 mm wide.

A DIN-rail terminal for wiring control cabinets, machine panels and distribution boards. Specifications: 2.5 mm², 26A 250V, 6.2 mm Wide, Three-Tier Sensor/Actuator DIN-Rail Terminal.
