JUKH125 Power Distribution Block – 125 A / 1000 V

The LEIPOLE JUKH125 is a single-pole, high-current connection block with one input and one output terminal for 10–35 mm² conductors. Rated 125 A to IEC (150 A UL/CSA) with 1000 V AC/DC IEC insulation voltage and IP20 protection. Individual modules are stackable for multi-pole applications.

Technical Specifications

Model JUKH125
Order number 5012.126
Poles 1 (modules stackable for multi-pole use)
Rated current 125 A (IEC); 150 A (UL/CSA)
Rated voltage Ui 1000 V AC/DC (IEC); 600 V (UL)
Short-time withstand current (Icw, 1 s) 4.2 kA rms
Peak withstand current (Ipk) 25 kA
Connections 1 × input, 1 × output
Conductor cross-section 10–35 mm² (AWG 8–1/0)
Tightening torque 6.4 N·m (57 lb-in)
Mounting hole spacing 61.6 mm
IP rating IP20

Packaging

Sales unit Pack of 6 pcs
Inner box quantity 6 pcs
Inner box dimensions 17 × 8.5 × 6 cm
Inner box gross weight 0.48 kg
Carton quantity 270 pcs
Carton dimensions 51 × 35 × 33 cm
Carton gross weight 21.44 kg

The LEIPOLE JUKH125 is a single-pole, high-current connection block with one input and one output terminal for 10–35 mm² conductors. Rated 125 A to IEC (150 A UL/CSA) with 1000 V AC/DC IEC insulation voltage and IP20 protection.

Specifications: 1000V IEC, 10–35 mm² In/Out.
